SKE POE 432P mini UPS 10400mAh, 5V, 9V, 12V & PoE Support

Multi-Voltage Output Support:
Voltage Output Usage Example
5V (USB) WiFi Router, ONU, Charging Devices
9V / 12V DC Routers, Switches, Security Cameras
PoE 15V/24V IP Cameras, PoE Switch, PoE WiFi Router
Battery & Backup:

Battery Capacity: 10400mAh (High-grade Lithium-Ion cells)

Backup Time: 4 to 10 hours (depends on load)

Battery Protection: Overcharge, Over-discharge, Overcurrent, Short Circuit Protection

Auto Switch: Automatic switching between AC power and UPS mode without rebooting the router

Ports & Connectivity:
Port Function
USB Output (5V) For USB-powered devices
DC Output (9V / 12V) For routers, CCTV
PoE Output (15V/24V) For PoE devices (Selectable voltage)
DC Input For charging the UPS
️ Safety & Protection:

Overcharge Protection

Overcurrent Protection

Short Circuit Protection

Temperature Protection

LED Indicators:

Power ON/OFF

Battery Charging

Battery Low

Mode Status (AC/UPS)

Specifications:
Feature Value
Model SKE POE 432P
Battery Type Lithium-Ion
Capacity 10400mAh
Input Voltage 100-240V AC (50/60Hz)
Output Voltage 5V / 9V / 12V (DC) + 15V/24V PoE
Backup Time 4–10 Hours (depends on device load)
PoE Support IEEE 802.3af / Passive PoE
Dimensions Compact & Portable
Weight Approx. 400g
Usage Scenarios:

Home WiFi Router & ONU Backup

PoE IP Camera / NVR Backup

VoIP IP Phone / Intercom Systems

CCTV Camera Backup

Small Office Network Devices

Remote areas with frequent load-shedding

Why Choose SKE POE 432P?

Supports both DC devices and PoE devices

Automatic switching during power failure

Multiple voltage support in one compact device

No need for separate batteries for routers or cameras

Improved battery life with updated 10400mAh capacity

Package Includes:

SKE POE 432P Router UPS

Multi-voltage adapter cables

PoE injector cable

User Manual
