Elevator price in Bangladesh: 1600KG / 21 Person Fuji Lift Technical Specification Discover the 1600KG/21 Person Fuji Lift, offering advanced technology, smooth operation, and safety features. Ideal for commercial and residential buildings with customisable options, energy-efficient performance, and compliance with international standards. General Information: - Model: Fuji Lift
- Capacity: 1600 kg (21 Persons)
- Speed: 1.0 m/s, 1.5 m/s, 1.75 m/s, 2.0 m/s (Configurable)
- Travel Height: Up to 60 meters (Customizable)
- Stops: Maximum 20 Stops
- Control System: Microprocessor-based VVVF (Variable Voltage Variable Frequency) Drive
- Operation System: Collective Selective Control (Full Automatic)
Elevator price in Bangladesh Car Dimensions: - Internal Car Size:
- Width: 1600 mm
- Depth: 2000 mm
- Height: 2400 mm
- Door Opening: Center Opening / Side Opening
- Door Width: 1100 mm
Machine Room Requirements: - Machine Room Location: Above the Shaft or Machine Room-Less (Optional)
- Motor Type: Gearless Traction Machine
- Power Supply: 3 Phase, 380V – 415V, 50/60 Hz
- Backup Power: Compatible with Emergency Power Supply
Safety Features: - Overload Detection System
- Automatic Rescue Device (ARD) for Power Failure
- Emergency Alarm and Intercom System
- Fire Emergency Return Function
- Over-speed Governor
- Buffer Springs in Pit Area
- Door Safety Edge Sensors and Infrared Curtains
Interior Design: - Wall Finish: Stainless Steel, Hairline / Mirror Finish (Customizable)
- Ceiling: LED Lighting with Acrylic Panels
- Flooring: PVC, Marble, or Granite Options
- Handrails: Stainless Steel Tubular Handrails
- Display: LCD / LED Indicators for Position and Direction
Performance Features: - Smooth Acceleration and Deceleration
- Noise-Free Operation
- Energy-Saving LED Lighting
- Regenerative Drive for Energy Efficiency (Optional)
- High-Performance Door Drive System with VVVF Control
Compliance Standards: - EN 81-20 / EN 81-50 Safety Regulations
- ISO 9001:2015 Certified
- ISO 14001:2015 Environmental Management
- CE Certified
- RoHS Compliant
Optional Features: - Touchless Button Control System
- Access Control System with RFID Card Reader
- CCTV Monitoring Inside Cabin
- Voice Announcement System
- Braille Buttons for Accessibility
Warranty and Support: - Warranty: 12 Months Standard Warranty (Extended Warranty Available)
- After-Sales Support: 24/7 Technical Support and Maintenance Services
10. Manufacturer Details: - Brand: Fuji Lift
- Origin: China/Japan
- Distributor: PS POWER, Bangladesh
