Lanner Model: FW-8894B 1U High Performance x86 Network Serve

Lanner Model: FW-8894B 1U High Performance x86 Network Appliance for Enterprise Firewall, UTM and IPS. 64GB RAM 2x2=4TB SSD.

Product details

1U High Performance x86 Network Appliance for Enterprise Firewall, UTM and IPS.

Dual CPU Sockets for Intel® E5-2600 v3/v4 (Haswell/Broadwell-EP) with Wellsburg PCH
4 NIC module slots up to 32 LAN ports
Support for Intel® 1G/10G/40G network controllers
Up to 25 Gbps QuickAssist crypto acceleration by Intel® DH8925
Supports DDR4 2133 MHz memory up to 512 GB
1+1 ATX redundant powers 650W
Optional TPM support
OPMA slot for IPMI
4 hot-swappable cooling fans with smart fan control

Specifications
Platform
CPU Dual Intel® Xeon® E5-2600 v3/v4 series CPU (Haswell/Broadwell-EP)
Chipset Intel C612 series Chipset
BIOS AMI BIOS 64 Mb
Memory Technology DDR4 2133 MHz (Registered ECC)
Memory Capacity 512GB
Memory Socket 16 x 288-pin DIMM
Storage
SATA storage 1 x 3.5” or 2 x 2.5” HDD drive bays (Hard drive is NOT included)
I/O
Ethernet controller 1 x Intel i210
Default LAN RJ-45, SFP or QSFP
Ethernet modules 4
Management ports One, share with IPMI port
USB 2.0 2 x Type A
IPMI via OPMA slot Optional
TPM Optional
Power and Mechanical
Power input 100~240V@47~63Hz
Type/Watt 1+1 ATX 650W redundant power supply units
Reset 1 x reset button, software reset by default
Processor cooling CPU heatsink with fan duct
System cooling 4x independent hot-swappable cooling fans with smart fan control
OS and Certifications
Operating System Windows 7, Windows 2008 Server, Linux kernel 2.6 or above
Certifications CE Class A, FCC Class A, RoHS
Physical and Environmental
Storage temperature -20°C to 70°C
Operating temperature 0°C to 40°C
Operating humidity 5% to 90% (non-condensing)
Storage humidity 5% to 95% (non-condensing)
Dimensions (W x H x D) 438 mm x 44 mm x 630 mm (17.24" x 1.73" x 24.80")
Weight 18 kg (39.6 lbs)
LCD module Character LCM with keypad (Graphic optional)
Watchdog Yes
Internal RTC Yes
Order Information
FW-8894A Support 4 Ethernet module slots & 2 hard drive bays, with Coleto Creek 8925
FW-8894B Support 4 Ethernet module slots & 2 hard drive bays.
