Digital Indicator Xk3190 D10

Tk 22,500
Seller info
Sold by:
BDScalesTechnology
Member since:
11 Jul 2016
Location:
Dhaka Motijheel
Safety tips:
Don’t pay in advance
Meet in a safe & public place
Description

DESCRIPTION for Digital Indicator Xk3190 D10 price in Bangladesh



Item Specifications

01.

Product Code

D10

02.

Price

22000

03.

Warranty Period

One Year

04.

Model

XK 3190-D10

05.

Stock

In Stock

06.

Origin

China (Jiangsu)

07.

Discount

None

08.

Accessories

Available

09.

Brand

YAOHUA





Description



Weighing indicator Control instrument XK3190-D10





Introduction



Weighing indicator XK3190-D10 adopts high precision ∑-Δ A/D conversion technology, widely applied in electronic floor scale,electronic truck scale,static railway scale and so on alike static weighing system equipped with 1~8 load cell.



Features:

AC/DC power supply

User-defined printing content and format:

User-defined printing format, and be able to connect with serial printing interface and thermal printer

Reliable shield and anti-jamming:

Adopts hardware for shielding and reduces external-jamming and damage of interface







Standard function

High precision A/D conversion with readability 1/30000

Auto change division among 3 different weighing ranges set up by user

Non-linearity correction, calibration tolerance correction

Password management and time power off function

Able to set up print function for auto/manual; no condition/under condition; daily/sorted statistics report printing

Weighing data save/check/delete/ protection in case of power off

Able to edit English letter referring to a numeric-letter table (like ASCII table), able to download English letter through PC;

Standard RS232 communication interface with selectable baud rate and communication method(RS422/RS485 optional)

Standard scoreboard interface with current loop(20mA)method and standard parallel printer interface

Able to print goods name, customer name, company name and notes in English

Standard and user-defined printing format in horizontal, vertical and record format etc

Able to save 1501 weighing records, 1500 truck records consisting of truck ID and corresponding tare weight; 201 goods records consisting of goods ID, goods name; 100 customer records consisting of customer ID, customer name, note info

Able to print any parameter of indicator for saving and referring

Hardware detection and voltage of load cell output displaying function

Appearance:











Technical parameters



A/D conversion method: ∑-Δ

A/D conversion speed: 200 times/sec

Input signal range:-30mV~30mV

Max. connection number of load cell: 8 at 350 ohm or 16 at 700 ohm

Load cell connection mode: 6 wire, auto compensation for distance≤50 meters

Verified counts: 3000

Readability:30,000

Max.internal reaolution:600,000

Display: 7 bits LED display 7 status indications,3 power indicators

Clock: real clock without effect when power off

Scoreboard interface (Standard)

Serially sending by 20mA current loop with baud rate 600,transmiaaion distance≤2000 meters

Communication interface( RS232 C standard; RS422 optional)

Serial communication interface, with selectable baud rate by continuous sending method or on command method

Print interface (Standard)

Parallel sending, able to connect with wide-line printer model KX-P1121,KX-P1131,LQ300K; micro printer for model D10P

Power supply: AC 187~242V,49~51Hz; DC 6V/10Ah battery
