JBL BAR 9.1 True Wireless Surround with Dolby Atmos

The JBL Bar 9.1 soundbar brings audio experience of a movie theater into your home with two detachable surround speakers and the added punch of Dolby Atmos® and DTS:X™ 3D sound. With 820 watts of total system power, you can enjoy every Oscar-worthy performance through powerful, crystal-clear audio. Turn up the 10’’ subwoofer for pulse-pounding bass or turn it down and relax with Chromecast and AirPlay music streaming. Immerse yourself in the latest blockbuster or re-live your favorite movie or sport scenes. The most incredible home cinema sound experience is here.5.1.4 channel

Yes

Power supply

100 - 240VAC, ~ 50/60Hz

Battery charge time

3 hours

Total speaker power output (Max. @THD 1%)

820 W

Main Soundbar output power (Max. @THD 1%)

400

Surround speakers output power (Max. @THD 1%); 2 x 60W

Yes

Subwoofer output power (Max. @THD 1%); 300

Yes

Soundbar transducer

4×racetrack drivers + 2 × up-firing full-range drivers+3 × 0.75” (20mm) tweeter

Surround transducer (per piece)

up-firing full-range driver + 0.75” (20mm) tweeter

Subwoofer transducer

10"

Operating temperature

0°C - 45°C

Standby for Soundbar (when all wireless connections are deactivated)

< 0.5 W

Networked standby (Soundbar)

< 6.0 W

Networked standby (Subwoofer)

< 2.0 W

Time to standby

<10 minutes

This equipment complies with European Commission Regulation (EC) No 1275/2008 and (EU) No 801/2013. The Soundbar unit is considered as networked equipment with high network availability (HiNA equipment and equipment with HiNA functionality) as it provides wireless network access point for two wireless Surround speakers and one wireless Subwoofer.HDMI In

1

HDMI eARC

1

HDMI HDCP version

2.3

103dB

Yes

34Hz~20KHz

Yes

1 Optical, Bluetooth, Chromecast, AirPlay2, USB

YesUSB port

Type A

USB rating

5 V/ 500 mA

Supported file format

MP3

MP3 codec

MPEG 1 Layer 2/3, MPEG 2 Layer 3, MPEG 2.5 Layer 3

MP3 sampling rate; 16 KHz - 48 KHz

Yes

MP3 bitrate

80 kbps - 320 kbps

USB Port; (USB playback is available in US version. For other versions, USB is for Service only.)

Yes

Bluetooth version

4.2

Bluetooth profile

A2DP V1.2/ AVRCP V1.5

Bluetooth frequency range; 2402MHz-2480MHz

Yes

Bluetooth Max. transmitting power

13dbm  (EIRP)

Modulation Type

GFSK, π/4 DQPSK, 8DPSK

Wi-Fi network

IEEE 802.11 a/b/g/n/ac (2.4GHz/5GHz)

2.4G Wi-Fi frequency range

2412 – 2472 MHz (2.4GHz ISM Band, USA 11 Channels, Europe and others 13 Channels)

2.4G Wi-Fi Max. transmitting power

20 dBm (EIRP)

Modulation Type

DBPSK, DQPSK, CCK, QPSK, BPSK, 16QAM, 64QAM

5G Wi-Fi frequency range

5.15 - 5.35 GHz, 5.470-5.725 GHz, 5.725 - 5.825 GHz

5G Wi-Fi Max. transmitting power

22 dBm (EIRP)

Modulation Type

QPSK, BPSK, 16QAM, 64QAM, 256QAM

5G Wireless frequency range

5180.0 - 5240.0MHz (Except Europe), 5725.0 - 5825.0MHz

5G Max. transmitting power

13 dBm (EIRP)

Modulation Type

QPSK
