ID CARD PRINTER -MIFARE, DESFire, HID iCLASS, UHF

ID CARD PRINTER =

MIFARE, DESFire, HID iCLASS, UHF

Direct-to-card dye-sublimation/Resin thermal transfer
• Single-sided printing, edge-to-edge, upgrade kit for
dual-sided printing as an option
• Standard 300 x 300 dpi resolution
• Customizable 300 x 600 dpi resolution (color and
monochrome printing) or 300 x 1200 dpi resolution
(monochrome printing only)
• 32 MB memory (RAM) standard - optional 64 MB1
• Dual-sided Card Lamination Module (CLM) as an option1
• Colors available: fire red & brilliant blue


PRINTING PERFORMANCES1

----------------------------

• Single side:
- Color (YMCKO): 190 - 225 cards/hour
- Monochrome: 800 - 1000 cards/hour
• Dual side:
- Color (YMCKO-K): 140 cards/hour


CARD MANAGEMENT AND SPECIFICATIONS

---------------------------------------

• Feeder capacity: 100 cards (0.76 mm – 30 mil)
• Output hopper capacity: 100 cards (0.76 mm – 30 mil)
• Open output hopper as an option for collecting cards one
by one
• Reject tray/output hopper capacity at the back: 50 cards
(0.76 mm – 30 mil)
• Card thickness: 0.25 to 1.25 mm (10 to 50 mil), gauge
adjustment (0.25 mm - 10 mil only for monochrome
printing)
• Card types: PVC cards, composite PVC cards, PET cards,
ABS cards1, special varnished cards1
• Card format: ISO CR80 - ISO 7810 (53.98 mm x 85.60 mm)

SIZE AND WEIGHT
• Size (H x W x D):
247 x 205 x 381 mm (9.72’’ x 8.07’’ x 14.99’’)
With reject tray/output hopper at the back:
247 x 205 x 487 mm (9.72’’ x 8.07’’ x 19.17’’)
• Weight: 4.02 kg (8.86 lbs)
With reject tray/output hopper at the back:
4.11 kg (9.06 lbs)
