800KG/10 Person Fuji Lift Price in Bangladesh

General Information
Model: Fuji Lift 800kg / 10 Person
Capacity: 800 kg / 10 persons
Brand: Fuji
Type: Passenger Elevator
Drive System: Gearless Traction Machine
Rated Speed: 1.0 m/s to 2.5 m/s (customizable based on requirements)
Travel Height: Up to 45 floors (customizable)
Control System: VVVF (Variable Voltage Variable Frequency) Drive
Door Operation: Automatic Center Opening / Side Opening
Door Safety System: Infrared Light Curtain Sensor
Technical Specifications
Machine Room: Machine Room / Machine Room Less (MRL) Options Available
Power Supply: 380V / 415V, 3-Phase, 50/60Hz
Motor Power: 5.5 kW – 11 kW (Based on Speed & Travel Distance)
Brake System: Electromagnetic Brake
Cabin Dimensions:
Internal Width: 1100 mm
Internal Depth: 1400 mm
Internal Height: 2400 mm
Door Dimensions:
Opening Width: 800 mm – 900 mm
Opening Height: 2100 mm
Pit Depth: Minimum 1400 mm
Overhead Height: Minimum 4200 mm
Guide Rails: T89/T125 Cold Drawn Steel Rails
Safety Gear: Progressive Safety Gear System
Buffer System: Oil or Spring Buffers
Emergency Landing Device: Provided (Battery Operated)
Overload Protection: Included
Interior Design Options
Cabin Material: Stainless Steel / Hairline Finish / Mirror Finish
Ceiling: LED Lighting with Decorative Panel Options
Flooring: PVC, Marble, Granite / Vinyl Tile
Handrails: Stainless Steel (Optional)
Display Panel: Digital LCD / LED Display
Control Panel: Microprocessor-Based with Braille Buttons
Safety Features
Emergency Alarm and Intercom System
Fire Emergency Return System
Earthquake Sensor (Optional)
Door Safety Edge Protection
Automatic Rescue Device (ARD) for Power Failure
Overload Sensor with Alarm
Speed Governor and Safety Gear System
Emergency Light and Fan
CCTV Surveillance System (Optional)
