Accuracy Class OIML R60 C3 Output Sensitivity ( = FS ) mV/V 2.0 ± 0.002 Maximum Capacity ( Emax ) t 10, 20, 25 30, 40, 50 Max. Number of Load Cell Intervals nLC 3000 Ratio of min. LC Verification Interval Y = Emax / vmin 15000 7500 Combined Error %FS ≤± 0.02 Creep Error (30 minutes) %FS ≤± 0.02 Temperature Effect on Zero (ZTC) %FS/10°C ≤± 0.02 Temperature Effect on Sensitivity (STC) %FS/10°C ≤± 0.02 Zero Balance %FS ≤± 1.5 Safe Overload %FS 150 Ultimate Overload %FS 300 Excitation, Recommended Voltage V 5 ~ 12 Excitation, Maximum Voltage V 18 Input Resistance Ω 700 ± 7 Output Resistance Ω 703 ± 4 Insulation Resistance (50V) MΩ ≥5000 Compensated Temperature °C -10 ~ + 40 Operating Temperature °C -35 ~ + 65 Storage Temperature °C -40 ~ + 70 Load Cell Weight kg 10t: 15 20t – 40t: ~17 50t: 25 Element Material Nickel plated alloy steel Ingress Protection (acc. to EN 60529) IP68 Recommended Torque on Fixation Bolts Nm 1100 ATEX Classification (optional) II 1G Ex ia IIC T4 Ga II 1D Ex ia IIIC T 200 135°C Da II 3G Ex ic IIC T4 |
