Intel® Core™ i3-7100U Processor

Essentials
Product Collection
7th Generation Intel® Core™ i3 Processors

Code Name
Products formerly Kaby Lake

Vertical Segment
Mobile

Processor Number
i3-7100U

Status
Launched

Launch Date
Q3'16

Lithography
14 nm

Use Conditions
Industrial Commercial Temp, Embedded Broad Market Commercial Temp, PC/Client/Tablet

Recommended Customer Price
$281.00
CPU Specifications
# of Cores
2

# of Threads
4

Processor Base Frequency
2.40 GHz

Cache
3 MB Intel® Smart Cache

Bus Speed
4 GT/s

TDP
15 W

Configurable TDP-down Frequency
800 MHz

Configurable TDP-down
7.5 W

Supplemental Information
Embedded Options Available
Yes

Datasheet
View now

Memory Specifications
Max Memory Size (dependent on memory type)
32 GB

Memory Types
DDR4-2133, LPDDR3-1866, DDR3L-1600

Max # of Memory Channels
2

Max Memory Bandwidth
34.1 GB/s

ECC Memory Supported ‡
No

Processor Graphics
Processor Graphics ‡
Intel® HD Graphics 620

Graphics Base Frequency
300 MHz

Graphics Max Dynamic Frequency
1.00 GHz

Graphics Video Max Memory
32 GB

Graphics Output
eDP/DP/HDMI/DVI

4K Support
Yes, at 60Hz

Max Resolution (HDMI)‡
4096x2304@24Hz

Max Resolution (DP)‡
4096x2304@60Hz

Max Resolution (eDP - Integrated Flat Panel)‡
4096x2304@60Hz

Max Resolution (VGA)‡
N/A

DirectX* Support
12

OpenGL* Support
4.5

Intel® Quick Sync Video
Yes

Intel® Clear Video HD Technology
Yes

Intel® Clear Video Technology
Yes

# of Displays Supported ‡
3

Device ID
0x5916

Expansion Options
PCI Express Revision
3.0

PCI Express Configurations ‡
1x4, 2x2, 1x2+2x1 and 4x1

Max # of PCI Express Lanes
12

Package Specifications
Sockets Supported
FCBGA1356

Max CPU Configuration
1

TJUNCTION
100°C

Package Size
42mm X 24mm

Advanced Technologies
Intel® Optane™ Memory Supported ‡
Yes

Intel® Speed Shift Technology
Yes

Intel® Turbo Boost Technology ‡
No

Intel vPro® Platform Eligibility ‡
No

Intel® Hyper-Threading Technology ‡
Yes

Intel® Virtualization Technology (VT-x) ‡
Yes

Intel® Virtualization Technology for Directed I/O (VT-d) ‡
Yes

Intel® VT-x with Extended Page Tables (EPT) ‡
Yes

Intel® Transactional Synchronization Extensions
No

Intel® 64 ‡
Yes

Instruction Set
64-bit

Instruction Set Extensions
Intel® SSE4.1, Intel® SSE4.2, Intel® AVX2

Idle States
Yes

Enhanced Intel SpeedStep® Technology
Yes

Thermal Monitoring Technologies
Yes

Intel® Flex Memory Access
Yes

Intel® Identity Protection Technology ‡
Yes

Intel® Stable Image Platform Program (SIPP)
No

Intel® Smart Response Technology
Yes

Intel® My WiFi Technology
Yes

Security & Reliability
Intel® AES New Instructions
Yes

Secure Key
Yes

Intel® Software Guard Extensions (Intel® SGX)
Yes with Intel® ME

Intel® Memory Protection Extensions (Intel® MPX)
Yes

Intel® Trusted Execution Technology ‡
No

Execute Disable Bit ‡
Yes

Intel® OS Guard
Yes

Intel® Boot Guard
Yes
