Sanwa CD800A Digital Multimeter

Product quantity- 1pcs, made in china.

Product Details
CD800A
Integrated case suitable for use and storage
3-3/4 Digits 4000 Count
Auto Power-off (Enable or Disable)
Captive test leads prevent confusion of measurement polarity
Conforms to IEC61010 and CAT III 600V Max

DC Voltage (V) 400m/4/40/400/600V
AC Voltage (V) 4/40/400/600V
DC (A) 40m/400mA
AC (A) 40m/400mA
Resistance (ohms) 400/4k/40k/400k/4M/40M
Diode Test Open Voltage: Approx 1.5V
Size (HxWxD) & weight 176x104x46mm, 340g
Specifications
Attribute Value
Absolute Maximum DC Current Measurement 400mA dc
Absolute Maximum AC Current Measurement 400mA ac
Absolute Maximum Resistance Measurement 40MΩ
Absolute Maximum AC Voltage Measurement 600V ac
Absolute Maximum DC Voltage Measurement 600V dc
Absolute Maximum Capacitance Measurement 100µF
Functions Measured AC Current, AC Voltage, Capacitance, Continuity, DC Current, DC Voltage, Diode, Frequency, Resistance
Maximum Frequency 1kHz
Model Number p CD800A
AC Current Measurement Resolution 0.01mA ac
DC Current Measurement Resolution 0.01mA dc
AC Voltage Measurement Resolution 0.001V ac
DC Voltage Measurement Resolution 0.1mV dc
Resistance Measurement Resolution 100mΩ
Capacitance Measurement Resolution 10pF
Best DC Voltage Accuracy ±0.7% + 3 Digits
Best AC Current Accuracy ±2.8% + 5 Digits
Best AC Voltage Accuracy ±1.6% + 9 Digits
Dimensions 46 x 104 x 176mm
Safety Category Level CAT III
Safety Category Voltage 600V
Weight 340g
Safety Category CAT III 600 V
Best Resistance Measurement Accuracy ±1.5% + 5 Digits
Height 176mm
Best Capacitance Measurement Accuracy ±5% + 10 Digits
Width 104mm
Battery Type AA x 2
Length 46mm
Best DC Current Accuracy ±2.2% + 5 Digits
