A68W WiFi IP Phone

www.ippbxbd.com

A68W Dual screen IP phone is the flagship products in IP telephone in the world. 4.3 inch TFT color display enhance the visual image of your desktop innovative paperless BLF+BLA maximize your working efficiency , the crystal clear broadband voice ( meet TIA920 standard) bring you the revolutionary working experience.



Dual screen mode maximize your convenience and efficiency of working

2D graphics accelerator design improves the UI operation very smoothly

Visualized LCD for BLF maximize your working efficiency

Top level voice quality

One core for instruction process and the other core for voice decoding greatly improve the sound quality and make it possible to run more complicated applications fluently.



A68W Specification
Basic functions
4.3″ TFT LCD, 480*272 Pixel, 6 SIP accounts, Call Forward, Call Transfer, Call Waiting, Hotline, Call Hold, Auto Answer, Caller ID, Redial, Mute, DND, Local 3-Way Conferencing, Speed Dial, Voice Mail, Local Phonebook (upto 400 entries), Direct IP call without SIP proxy, Black list, White list, Dialed/Rece ived/Missed/Forward call (total 400), Call Center Headsets mode,support EHS headset
Management
Configurable through web interface/phone, Provisioning: Auto-provision via FTP/TFTP/HTTP/HTTPS, DHCP Option 66, Redirection and Provisioning Service(RPS)

IP PBX Features
Intercom, Paging, Call pickup, Call park, Anonymous call, Anonym ous call rejection, Hold on music, Conference Call, Group pickup, DND&Call forward state synchronization, Call Recording
Physical
Power Interface: DC 5V-1A, PoE power supply: IEEE 802.3af Class 2 2x RJ45 100/1000M adaptive Ethernet ports, 1x RJ9 headphone jack, 1x RJ9 handset jack

Mult-language
English, German, Italian, French, Spanish, Portuguese, Russian, Chinese, Arabic, Polish, Turkish ， Hebrew
Keys Features
1 status indicator, 4 line keys, 4 soft keys, 5 navigation keys, 1 vo lume keys, 8 function keys (menu, cancel, hold, voicemail, mute, headphone, redial, hands-free)

Advanced Features
LDAP, Microsoft active directory(AD) server, XML remote phonebook,TR069,Action URL
Temperature and Humidity
Operating temperature: -10 ~ 50°C, Operating humidity: 10 ~ 90%

Audio Features
10( own ring tone,+ custom ring tone article), 8 volume adjustable + Mute mode, Narrowband codec: G.711(a/μ), G.729A/B/AB, G.726, iLBC, Wideband codec: G.722, L16, Support VAD, CNG, AEC, PLC, AJB, AGC, Full-duplex speakerphone with AEC
Management
Configurable through web interface/phone, Provisioning: Auto-provision via FTP/TFTP/HTTP/HTTPS, DHCP Option 66, Remote Provision Service(RPS)

Network Features
LAN / PC: support bridge mode, Open VPN, IPv4&IPv6,SIP connection mode: Proxy mode, and P2P mode, Support DNS SRV (RFC3263). NAT transverse: STUN mode. DTMF: In-band, RFC2833, SIP INFO, Support QoS, HTTP / HTTPS web server, Package tracing export, Syslog
Package
Qty/CTN: 10 PCS , G.W/CTN: 16KG, Giftbox size: 29 0m m(L)*200mm ( W ) *120mm(H) Carton Meas: 615mm(L) *405mm(W) *310mm(H)
