SONY BRAVIA 65 INCH X9300D 4K HDR TV FULL SPECIFICATION
2016 Model Year
WEIGHT DIMENSIONS
Screen Size------- 65"(64.5")
Screen Size ----- 163.9cm
Dimension of TV without Stand ----- Approx. 1458 x 839 x 36 mm (W x H x D)
Dimension of TV with Stand----- (W x H x D)----Approx. 1458 x 891 x 275 mm
Dimension of TV with Floor Stand (W x H x D Approx. 1651 x 1005 x 198 mm
Dimension of Package Carton (W x H x D) Stand Width Approx. 450 mm
300 x 200 mm VESA® Hole Pitch(W x HXD)
Approx. 28.9 kg Weight of TV without Stand
Approx. 32.1 kg Weight of TV with Stand
Approx. 44 kg Weight of Package Carton (Gross)
CONNECTIVITY
802.11a/b/g/n/ac Wi-Fi StandardWi-Fi Certified
1 (side) Ethernet inputs
Profile support Bluetooth Version 4.1 HID (mouse/keyboard connectivity)/HOGP (Low Energy device connectivity)/3DSP(3D GLASSES)/SPP(Serial Port Profile)
Screen mirroring(Miracast) Smartphone connectivity
Connection Input(s) RF (Terrestrial/Cable)------ 1(Side)
1 (Rear) Component Video (Y/Pb/Pr) Input(s)
Composite Video Input(s)
2 (1Side Analog Conversion/1Rear Hybrid with Component) RS-232C Input(s)
HDMI inputs total------- 4(1outside, 3center)
HDCP HDCP2.2-------------(for HDMI™1/2/3/4)
No MHL
(ARC) HDMI Audio Return ChanneL
1 (Side) Digital Audio Output(s)
Audio/ Output Headphone (s) (Side/Hybrid with Headphone and Subwoofer Out) 1
3 (side) USB ports
∅ USB HDD Recording
FAT16/FAT32/exFAT/NTFS USB drive format support
USB playback codecs
MPEG1:MPEG1/MPEG2PS:MPEG2/MPEG2TS(HDV,AVCHD):MPEG2,AVC/MP4(XAVC S):AVC,MPEG4,HEVC/AVI:Xvid,MotionJpeg/ASF(WMV):VC1/MOV:AVC,MPEG4,MotionJpeg/MKV:Xvid,AVC,MPEG4,VP8.HEVC/WEBM:VP8/3GPP:MPEG4,AVC/MP3/ASF(WMA)/WAV/MP4AAC/FLAC/JPEG
PICTURE (PANEL)
LCD Display type
(H x V, pixels) 3840x2160 Display resolution
Active3D capability
Backlight type------ Edge LED(Slim Backlight Drive)
Local Dimming Backlight dimming type
PROCESSING PICTURE
Compatibility HDR (High Dynamic Range)
4K Processor X1™ Picture processor
Enhancement Clarity-----4K X-Reality™ PRO
Enhancement Colour TRILUMINOS™ Display
Contrast enhancement--- X-tended Dynamic Range-- PRO
Motion enhancer Motionflow-XR 800(native100Hz)
SPEAKERS AND AMPLIFIER SOUND
7.5W+7.5W+7.5W+7.5W--- Audio Power Output
Speaker Type Main: Bass Reflex Speaker, Woofer: Bass Reflex Speaker
SOUND (PROCESSING)
Dolby audio format support Dolby™ Digital, Dolby™ Digital Plus, Dolby™ Pulse
DTS audio format support DTS Digital Surround
FM Radio
ClearAudio+ Sound processing
S-Force Front Surround Simulated surround sound
Standard/ Cinema/ Live Football/ Music Sound modes
SOFTWARE
Android Operating System
16GB On-board Storage (GB)
Content Bar and Voice Search
Electronic Program Guide (EPG) Internet Browser Opera
Application Store Yes(Google Play Store)
On/Off Timer with Sleep Timer
Teletext Yes Twin Picture No
(Analog/Digital) Closed Captions
POWER AND ENERGY SAVING Energy Label Rating-163.9cm Screen Size (cm, measured diagonally)
65"(64.5") Screen Size (inch, measured diagonally)
Power Consumption (in operation)-225W
619kWh/Year Annual Power Consumption—
0.5W Power Consumption (in standby)
Power Consumption (Networked Standby Mode) – Terminals
Peak luminance ratio for--- EU Presence of lead No
Mercury content (mg) Power Consumption (On Mode) for Energy Star
Standby Mode) for Energy Star Power Consumption
Energy Star® compliant -
DC 24V-Power Requirements (voltage/frequency)
Power Saving Mode / Back Light Off Mode
Dynamic Backlight Control
Light Sensor
DESIGN
Black Frame colour
BUILT-IN TUNER Silver Slate Stand design
ACCESSORIES
Wallmount Bracket:SU-WL450(Terminal access limitation) Optional accessories
Wireless Subwoofer:SWF-BR100;3D Glasses:TDG-BT500A- Optional accessories
