Hydraulic gsm cutter and Balance

Specifications
Place of Origin:
Guangdong, China (Mainland)
Brand Name:
Custer
Model Number:
CU-268
Power:
manual operation
Usage:
Textile Testing Instrument
Material:
aluminum
Cutting area:
100sq. cm
Sample diameter:
112.84mm
Sample thickness:
0.1mm-10mm
Outer dimensions:
34*34*24cm
Product name:
Manual Textile Fabric Swatch Cutter
Packaging & Delivery
Packaging Details:
Carton Paper Box and Air Bubble film or custom-made.
Delivery Detail:
Shipped in 3 days after payment

GSM Fabric Circle Hand-press Sample Cutter With Round Blade Knife
Product Description
This hand press sample cutter cutting die was made of Japan stainless steel. Cutting material are including: Textile, Leather, AL film, Carpet, Plastic, Polyfoam board, Paper, Carbon composite material and so on. Fashionable appearance & Simple operation. Can cut several layers at one time. We offered different cutting die for one sample machine use, such as 100 sq.cm, 50sq.cm, 38sq.cm, 25sq.cm, 20sq.cm, 10sq.cm, (other size and shapes can be customized).
Detailed Images
GSM Fabric Circle Hand-press Sample Cutter With Round Blade KnifeGSM Fabric Circle Hand-press Sample Cutter With Round Blade KnifeGSM Fabric Circle Hand-press Sample Cutter With Round Blade KnifeGSM Fabric Circle Hand-press Sample Cutter With Round Blade KnifeGSM Fabric Circle Hand-press Sample Cutter With Round Blade KnifeGSM Fabric Circle Hand-press Sample Cutter With Round Blade Knife
GSM Fabric Circle Hand-press Sample Cutter With Round Blade Knife
Advantages
I. Using Japan imported fine knife, sharp and durable, cutting the materials can include textiles, carpets, leather, aluminum foil, plastic, styrofosm, paper, advanced carbon fiber composite materials.
II. High-grade aluminum fuselage, simple and convenient, fast, multilayer cutting fabric, improve work efficiency
III. Multi-usage, can choose cutting die 100/50/38/25/20/10 sq.cm (Other specifications ans shapes can be customized)
IV. Structure application of hand pressure type cutting principle, don't go, don't cut, cutting accuracy is 100%, ans the complete, high efficiency, save energy, reduce material waste, reduce workload, reduce production costs.
Technical Parameter
Industrial Aluminium Hand Round Corner Cutter Fabric GSM Cutter
Material
aluminum
Cutting Area
100 sq.cm
Cutting Thickness
0.1mm-10mm
Machine Size
34cm*34cm*24cm(1-2cm) tolerance
Blade Diameter
112.84mm
All shapes can be customized according to drawing or sample.

Fabric weight balance schroder -GSM200

Detailed Product Description
Specifications:
Built-in four display units g, g/m2, oz, oz/yd2
Max. Capacity 200g x 0.01g, 20,000g/m2 x 1g/m2, 7 oz x 0.0005

Schröder Fabric Weight Balance
Specifications:
Built-in four display units g, g/m2, oz, oz/yd2
Max. Capacity
200g x 0.01g, 20,000g/m2 x 1g/m2, 7 oz x 0.0005oz, 590 oz/yd2 x 0.05oz/yd2
Platform Size Diameter 100mm (Round)
Completed With Plastic Wind Shield
Power Supply 12 VAC ~150mA Adapter or 6 x AA Batteries
