Fluke 45 dual display multimeter

Maximum Versatility In a Single Instrument

The Fluke 45 is a feature-rich 5-digit, 100 000 count meter that truly fits all applications and virtually any measurement need on the workbench or in the field. Two multifunction displays and 16 different measurement capabilities allow wide ranging versatility at an affordable price. The Fluke 45 delivers high performance and flexibility for manufacturing test, depot and field service, as well as R&D applications.

Multifunction vacuum fluorescent dual display allowing the user to measure two different parameters of the same signal from one test connection, and view both measurements at the same time.
True-rms voltage and current, including ac + dc
RS-232 interface standard, IEEE-488.2 option
Frequency measurement to 1 MHz
dB measurements: 21 selectable reference impedances. From 2 to 8000, and audio power from 2Ω to 16Ω
Compare (Hi/Lo/Pass) function for quick in-tolerance tests
0.05% dc current accuracy for 4-20 mA current loop service
Closed-Case Calibration: Calibration can be performed via the RS-232 (or optional IEE-488.2) interface or manually from the front panel. No internal adjustments are required
Optional FlukeView Forms, accessory software package; allows quick set-up and effortless communication between the Fluke 45 and an IBM PC or compatible. Custom forms are easily created, saved, and recalled

Features at a Glance:

Multifunction Vacuum Fluorescent Dual Display
True-RMS Voltage and Current Measurement, Including AC + DC
0.05% DC Current Accuracy for 4-20 mA Current Loop Service
Standard RS-232 Interface
Optional IEEE-488.2 Interface
Frequency Measurement to 1 MHz
dB Measurements
MIN/MAX Mode
RELATIVE Mode
COMPARE (Hi/Lo/Pass) for Quick In-Tolerance Tests
Closed Case Calibration
Optional: Rack-Mount Kit
