Tenda Router

Hardware Features
Protocols & Standards IEEE 802.3/3U IEEE 802.11n/g/b
Wired Interface 1 10/100Mbps WAN Port
3 10/100Mbps LAN Ports
Antenna 3 fixed 5dbi Omni Directional antennas
Button 1 Reset/WPS Button
Dimensions (L*W*H) mm 190mm*122.17mm*32.86mm
Wireless Features
Wireless Link Rate IEEE 802.11n: up to 300Mbps
IEEE 802.11g: up to 54Mbps
IEEE 802.11b: up to 11Mbps
Frequency Range (GHz) 2.412GHz-2.472GHz
Working Mode AP
WISP
WDS Bridge
Wrieless Security 64/128bit WEP
WPA-PSK
WPA2-PSK
WPS support
Wireless Function Enable/Disable Wireless Radio
Wireless Access Control
Reception Sensitivity b mode:1M -92dBm@8% 11M -87dBm@8% PER;
g mode:54M -72dBm@8% PER;
n mode:72.2M -68dBm@8% PER; 150M -68dBm@8% PER;
Software Features
Internet Connection Type Dynamic IP?PPPOE?Static IP?L2TP?PPTP
DHCP Built-in DHCP server
DHCP Client List
Address Reservation
Virtual Server Port Forwarding
DMZ Host
Parental Control Client Filter
Mac Filter
Websites Filter
Dynamic DNS No-IP
dyndns
VPN Pass-Through PPTP
L2TP
Other Advanced Function Bandwidth Control
Mac Address Clone
Remote Web Management
System Log
Others
Package Contents Wireless N300 Home Router F303
Quick Installation Guide
Ethernet cable
Power adapter
Resources CD
Environment Operating Temperature: 0?~40?
Storage Temperature: -40?~70?
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
Certificates FCC, CE,RoHs
