| Physical dimensions | 5.7"W x 7.7"H x 2.0"D (14.5 x 19.5 x 5.1 cm) |
| Display size, WxH | 3.6"W x 6.0"H (9.1 x 15.2 cm); 7.0" diag (17.78 cm) |
| Display resolution, WxH | 480 x 800 pixels |
| Display type | bright, color WVGA TFT with adjustable backlighting |
| Weight | 35.7 ounces (1012 g) with battery pack; 22.4 ounces (635 g) without battery pack; 12.7 ounces (361 g) RAM mount |
| Battery | rechargeable, replaceable Nickel-Metal Hydride |
| Battery life | up to 3 hours with full backlight |
| SBAS/WAAS receiver | high-sensitivity with WAAS position accuracy |
| Voltage range | Nov-40 |
| IFR or VFR | VFR |
| Traffic Information Services (TIS) alerts compatible | Yes |
| Maps & Memory |
| Basemap | Yes |
| Ability to add maps | Yes |
| Built-in memory | internal solid state |
| Accepts data cards | yes (SD cards) |
| Waypoints/favorites/locations | 3,000 |
| Routes | 50 |
| Navigation database (includes Jeppesen® data) | Yes |
| Navigation database coverage areas | Americas or Atlantic or Pacific |
| Types of Jeppesen data | full and ARTCC, FSS frequencies and final approach waypoints |
| Preloaded Terrain database | Yes |
| Preloaded Obstacle database | Yes (U.S. and Europe only) |
| Preloaded SafeTaxi™ airport diagrams | Yes (U.S. only) |
| Preloaded AOPA Airport Directory | Yes (U.S. only) |
| Preloaded Garmin FliteCharts® | Yes (U.S. only) |
| Preloaded low & high altitude enroute airways | Yes |
| Preloaded private airports | Yes (U.S. only) |
| Moving map | Yes |
| Patented panel page | Yes |
| HSI (GPS-based) | Yes |
| IFR map mode | Yes |
| Audible terrain alerts | Yes |
| Terrain resolution | standard |
| Smart Airspace Feature (generates and displays altitude-sensitive alerts) | Yes |
| Automatic logbook | Yes |
| Separate serial and USB interfaces | Yes |
| Additional | GPS receiver has a nominal operating velocity range of 0 – 800 kts (411 m/s) |
| In The Box Accessories | GPSMAP 695 Free single database update Free trial FliteCharts® subscription certificate Yoke mount GA 25 remote antenna with suction cup mount 12/24 volt power cable AC power adapter USB cable MapSource® Trip & Waypoint Manager Protective cover Owner’s manual Quick reference guide |
