| CPU | Dual Core Intel® Core™ i3-3220 Processor 3.3 GHz | | Memory | System memory: 4 GB DDR3 RAM
Memory module pre-installed: 4 GB x1
Total memory slots: 4
Memory expandable up to: 32 GB (8GB x4)
Note: - When upgrading RAM to more than 28GB, the original 4GB RAM modules must be removed.
- For the information of RAM module installation and compatible NAS models, please refer to the QNAP RAM Module Installation Guide
| | Flash Memory | 512MB DOM | | Hard Drive | 8 x 3.5” or 2.5” SATA 6Gb/s, SATA 3Gb/s hard drive or SSD
NOTE: - The standard system is shipped without hard drives.
| | Hard Drive Tray | 8 x hot-swappable and lockable tray | | LAN Port | 4 x Gigabit RJ-45 Ethernet port (Optional dual-port 10 Gb and 1 Gb network card are supported)
NOTE: - For the information of network card installation, please refer to chapter 6 in the Turbo NAS Hardware Manual.
| | LED Indicators | Status, 10 GbE, LAN, eSATA, hard drives | | USB | 2x USB 3.0 port (rear)
4x USB 2.0 port (rear) Support USB printer, pen drive, USB hub, and USB UPS etc. | | eSATA | 2 (rear) | | Buttons | System: Power button and reset button | | LCD Panel | Mono-LCD display with backlight,
Enter button, Select button for configuration | | Alarm Buzzer | System warning | | Form Factor | 2U, Rackmount | | Dimensions | 88(H) x 439(W) x 520(D) mm
3.46(H) x 17.28(W) x 20.47(D) inch | | Weight | Net weight (NAS only) : 12.52 kg/27.61 lb
Gross weight (with packing and accessories) : 19.75 kg/43.54 lb | | Sound Level (dB) | Standby: 54.57 dB
In operation: 54.6 dB
(with 8 x 1TB hard drives installed) | | Power Consumption (W) | Sleep mode: 68W
In Operation: 130W
(with 8 x 1TB hard drives installed) | | Temperature | 0~40˚C | | Humidity | 5~95% RH non-condensing, wet bulb: 27˚C | | Power Supply | Input: 100-240V AC, 47-63Hz
Output: 300W | | Expansion Slot | 2 (for network and storage expansion) | | VGA | Reserved for system maintenance | | Fan | 3 x 6 cm smart cooling fan | |  | | Remark:
The TS-x79 rack mount models comply with ANSI/EIA-RS-310-D rack mounting standards. Before purchasing the server racks for these models, please make sure the server racks conform to the following criteria:
1. Rack size
A. Mounting post width: ≥ 451mm
B . Panel width: ≥ 500mm
C. Mounting post depth: 650mm~850mm  2. If the NAS is to be installed in a rack, a rack shelf or QNAP rail kit (optional purchase) is required. 3. The optional rack kits for the TS-x79 rack mount models are only compatible with square-hole server racks.  | Software Specification | Operating System Supported Clients - Windows XP, Vista, Windows 7/8 (32/64-bit), Windows Server 2003/2008 R2
- Apple Mac OS X
- Linux & UNIX
Supported Browsers - Microsoft Internet Explorer 8, 9
- Mozilla Firefox 8, 9, 10
- Apple Safari 4, 5
- Google Chrome
Multilingual Support - Chinese (Traditional & Simplified), Czech, Danish, Dutch, English, Finnish, French, German, Greek, Hungarian, Italian, Japanese, Korean, Norwegian, Polish, Portuguese (Brazil), Romanian, Russian, Spanish, Swedish, Thai, Turkish
File System - Internal Hard Drive: EXT3, EXT4
- External Hard Drive: EXT3, EXT4, NTFS, FAT32, HFS+
Networking - TCP/IP (IPv4 & IPv6: Dual Stack)
- Multiple Gigabit NICs with Jumbo Frame
- Failover
- Multi-IP Settings
- Port Trunking/NIC Teaming (Modes: Balance-rr, Active Backup, Balance XOR, Broadcast, IEEE 802.3ad/Link Aggregation, Balance-tlb and Balance-alb)
- Service Binding based on Network Interfaces
- Virtual LAN (VLAN)
- DHCP Client, DHCP Server
- Protocols: CIFS/SMB, AFP (v3.3), NFS(v3), FTP, FTPS, SFTP, TFTP, HTTP(S), Telnet, SSH, iSCSI, SNMP, SMTP, and SMSC
- UPnP & Bonjour Discovery
- USB Wi-Fi Adapter Support
Backup Solution - Real-time Remote Replication (RTRR)
- Works as Both RTRR Server & Client with Bandwidth Control
- Real-time & Scheduled Backup
- Encryption, Compression, File Filter, and Transfer Rate Limitation
- Block-level Remote Replication
- Works as Both Rsync Server & Client with Bandwidth Control
- Encrypted Replication between QNAP NAS Servers
- Desktop Backup by QNAP NetBak Replicator for Windows
- Apple Time Machine Support with Backup Management
- Data Backup to Multiple External Storage Devices
- Data Backup to Cloud Storage (Amazon S3, ElephantDrive, and Symform)
Security - IP Filter and Policy-based Automatic IP Blocking
- Network Access Protection with Auto-blocking: SSH, Telnet, HTTP(S), FTP, CIFS/SMB, AFP
- Encrypted Access: HTTPS, FTP with SSL/TLS (Explicit), SSH/SFTP (admin only), Encrypted Remote Replication between QNAP NAS Servers (Rsync over SSH)
- CIFS Host Access Control for Shared Folders
- Antivirus Protection
- FIPS 140-2 Validated AES 256-bit Volume-based Data Encryption*
- AES 256-bit External Drive Encryption*
- Importable SSL Certificate
- Instant Alert via Email, SMS, Instant Messaging (Windows Live Messenger), and Buzzer
Disk Management - Single Disk, JBOD, RAID 0, 1, 5, 5 + Hot Spare, 6, 6 + Hot Spare, 10, 10 + Hot Spare
- Online RAID Capacity Expansion & Online RAID Level Migration
- Bad Block Scan & Hard Drive S.M.A.R.T.
- Global Hot Spare Drive (4-bay NAS and above)
- RAID Recovery
- Bitmap Support
| iSCSI (IP SAN) - iSCSI Target
- Multi-LUNs per Target
- Up to 256 Targets/LUNs Combined
- Supports LUN Mapping & Masking
- Online LUN Capacity Expansion
- Supports SPC-3 Persistent Reservation
- Supports MPIO & MC/S
- iSCSI LUN Backup, One-time Snapshot, and Restore
- iSCSI Connection and Management by QNAP Finder (Windows)
- Virtual Disk Drive (via iSCSI Initiator)
- Stack Chaining Master
- Max No. of Virtual Disk Drives: 8
Server Virtualization & Clustering - Supports VMware vSphere
- Supports Citrix XenServer
- Supports Windows Server 2008 R2 Hyper-V & Failover Clustering
Power Management - Wake on LAN
- Internal Hard Drive Standby Mode
- Scheduled Power on/off (Max 15 Settings)
- Automatic Power on after Power Recovery
- USB and Network UPS Support with SNMP Management
Access Right Management - Max No. of Users: 4,096
- Max No. of User Groups: 512
- Max No. of Network Shares: 512
- Batch Users Creation
- Import/Export Users
- User Quota Management
- Subfolder Permissions Support for CIFS/SMB, AFP, FTP and Web File Manager
Domain Authentication Integration - Microsoft Active Directory (AD)
- LDAP Server
- LDAP Client
- Domain Users Login via CIFS/SMB, AFP, FTP, and Web File Manager
MyCloudNAS Service - Private Cloud Storage and Sharing
- Free Host Name Registration (DDNS)
- Auto Router Configuration (via UPnP)
- MyCloudNAS Connect for Easy Connection (Windows utility)
Storage Plug & Play - Windows Software: QNAP Finder
- Create and Map Shared Folders
- Create and Connect to iSCSI Target/LUN
Web Administration - AJAX-based User Interface
- Smart Fan Control
- Dynamic DNS (DDNS)
- SNMP (v2 & v3)
- Resource Monitor
- Network Recycle Bin for File Deletion via CIFS/SMB and AFP
- Comprehensive Logs (Events & Connection)
- Syslog Client
- Firmware Live Update
- System Settings Backup and Restore
- Restore to Factory Default
