OSRAM LED Tube Light

4' OSRAM LED Tube Light: 20W 6500K,
Model: SubstiTUBE® Trio 2

Linear LED lamp in T8 shape with G13 socket
 Suitable for operation with magnetic ballast
 Direct retrofit for CCG luminaires; replacement of lamp and including starter and no rewiring is necessary
 Polycarbonate cover
 Full integrated electronic driver complies to relevant standards
 CRI 80-85
 Complies with draft of relevant safety standards
 Power factor > 0.9
 More than 30,000 hours lifetime
 Overpower, overheat, short and open circuit protected
 High color and light homogeneity
 RoHS-conformity, no mercury
 Not for operation with ECG, not suitable for dimming
Rated Voltage: 220-240V~, 50/60Hz,
Power Factor: >0.9 @ direct mains, >0.9 @ CCG non compensated
Safety Protection: Short circuit protection / open loop protection,
Flammability: Glow wire test (650°C)
Insulation class: IEC 61347-2-13
Safety Requirements IEC 60598-1 + IEC 61347-2-13 + IEC 61195 +
IEC 60061 + IEC 62776 proposal
Environment: RoHS
EMC / radio disturbance characteristics: EN 55015 (CISPR 15)
EMC / immunity: IEC 61547 (IEC 61000-3-2 and -3-3)

OSRAM
Installation Instructions
 Please ensure that the voltage supply is disconnected.
 Carefully remove the fluorescent tube and conventional starter according to the lamp holder type.
 Insert SubstiTUBE® Trio and SubstiTUBE® Starter properly.
Below an example for typical lamp holder types is described
 Turn the conventional lamp 90° degrees and take it out of the socket.
 Remove the conventional starter by turning it.
 Insert and latch the SubstiTUBE® Start into starter socket.
 Insert SubstiTUBE® Trio into socket and locate into position by turning 90°. Check light emission direction

Safety and Application notes
 The SubstiTUBE® Trio must be handled with care, and do not operate the product that in a damaged condition.
 When operating with CCG (magnetic ballast), SubstiTUBE® Starter has to be inserted to replace the conventional fluorescent lamp starter as well. If the conventional starter is not replaced, the SubstiTUBE® Trio will start blinking and be damaged!
 Do not use SubstiTUBE® Trio in luminaires which do not have any conventional starter or whereby the conventional starter cannot be replaced.
 Not suitable for luminaires with serial lamp connection i.e. more than one tube at one magnetic ballast.
 The SubstiTUBE® Trio Trio lamp emits light at limited angle, unlike conventional fluorescent tube in 360° omni direction.
 Due to the light distribution characteristic of the SubstiTUBE® Trio, the resulting luminaires light characteristic is likely to change. It is not guaranteed that e.g. standards for lighting at working places will be complied with after replacement. A photometric check of the installation is highly recommended.
 The effective energy savings depend on the efficiency of the luminaires setup to be replaced and should be considered individually case by case basis. Particularly magnetic ballast losses are reduced to ohmic losses and are typically only about 1 W.
 The SubstiTUBE® Trio is protected according to IP20. Applications with external risk of moisture and dust can be served with an adequately protected luminaires.
 SubstiTUBE® Trio may also be driven directly on line voltage. In order to grant a safe operation mode please refer to the application note for installation information.
 Photobiological Safety of Lamps and Lamp Systems according to IEC 62471 Risk Group: Exempt.
