OSRAM Energy Saving Lamp

23W Energy Saving Lamp: LBD/HC/26.5 Minitwist 23W/865 (Daylight) E27, 240V, OSRAM

Areas of application
a. General illumination
b. Domestic applications
c. Wherever compact and efficient lamps are needed
d. Wherever cold light colors are needed
e. Outdoor use in enclosed and ventilated luminaires only

Product benefits
a. Fast return on investment
b. Compact dimensions
c. Up to 80 % less energy consumption compared with ordinary light bulbs

Product features
a. Available in 2 light colors: 827 and 865
b. Also available in activating light color LUMILUX Cool Daylight
c. Average life: 6,000 h


Technical data:
Electrical data-
Nominal wattage: 23.00 W
Rated wattage: 23.00 W
Nominal voltage: 220…240 V
Power factor: λ 0.55
Nominal current: 0.23 A
Operating frequency: 50…60 Hz

Photometrical data-
Nominal luminous flux: 1600 lm
Rated luminous flux: 1600 lm
Color temperature: 6500 K
Light color: 865
Light color as per EN 12464-1: Cool Daylight
Color rendering index Ra: ≥80
Color rendering group: 1B
Light technical data-
Warm-up time (60 %): 20.00 s
Starting time: 0.3 s

Dimensions & weight-
Maximum diameter: 54.0 mm
Overall length: 119.0 mm
Product weight: 75.00 g
Product datasheet
Temperatures-
Ambient temperature range: 0…+50 °C

Lifespan-
Nominal lamp life time: 10000 h
Rated lamp life time: 10000 h
Number of switching cycles: 10000
Lumen main.fact.at end of nom.life time: 0.65

Additional product data-
Base (standard designation): E27
Lamp mercury content: 1.4 mg
Appropriate disposal acc. to WEEE: Yes

Capabilities
Dimmable: No
Certificates & standards
Energy efficiency class: A
Energy consumption: 23 kWh/1000h
