Wifi IP CAmera

Item Specification PTK-IP04SL
Imaging Device 1/3-in. progressive-scan Sony sensor with wide dynamic range
Image Control Automatic white balance (AWB), automatic back lighting, automatic gain control (AGC), automatic exposure (AE), auto/manual iris
Dynamic Range 102 dB typical/120 dB maximum
Minimum Illumination • Color mode: F1.4 @ 0.65 lux
• Black and white mode: F1.4 @ 0.08 lux
Lens Selection Accepts manual or DC auto iris lens
Lens Mount CS mount
Shutter Speed Electronic shutter
Video Compression MPEG-4 SP level 0 to 4, ASP level 0 to 5
Mega pixel 12.5 /1080 TVL
Resolution and Frame Rate • NTSC/PAL
• 1080 x 1020/576 @ 30/25 fps (D1)
• 1080x 1020/576 @ 30/25 fps (4CIF)

Video Streaming • Single-stream MPEG-4 up to D1 1080 x 1020/576 @ 30/25 fps
• Single-stream MJPEG up to D1 1080 x 1020/576 @ 15 fps
• Dual-stream: MPEG-4 and MJPEG
• Primary stream MPEG-4 programmable up to 704 x 480/576 @ 25/20 fps
• Secondary stream MPEG-4/MJPEG (selectable) programmable up to 352 x 240/288 @ up to 15 fps
Protocols* Dynamic Host Control Protocol (DHCP), File Transfer Protocol (FTP), Hypertext Transfer Protocol (HTTP), Secure HTTP (HTTPS), Network Time Protocol (NTP), Real-Time Transport Protocol (RTP), Real-Time Streaming Protocol (RTSP), Simple Mail Transfer Protocol (SMTP), Secure Sockets Layer/Transport Layer Security (SSL/TLS), Transmission Control Protocol/Internet Protocol (TCP/IP)
Power • 12 VDC, through optional external power supply, available separately
