Planet ICA-HM101W 2 MP Wireless Camera

Specification:
Image device 1/3” 2 mega-pixel CMOS image sensor
Lens 4.3 mm, fixed iris, fixed focus
Angle of view : horizontal: 56 degrees / vertical: 43 degrees
Effective Pixels 1600 x 1200 (UXGA)
Min Illumination 0.5 lux @ F1.2
LED IR LED x 12, 850nm
Built-in IR illuminators, effective up to 5~10 meters
PIR Sensor Built-in 6m / 120 degrees coverage
Video
Video Encoder H.264 / MPEG-4 / M-JPEG
Video Resolution 2M mode
H.264: 1600 x 1200 / 640 x 480 / 320 x 240 / 160 x 120
M-JPEG: 1600 x 1200 / 640 x 480 / 320 x 240 / 160 x 120
MPEG4: 1600 x 1200 / 640 x 480 / 320 x 240 / 160 x 120
720P mode
H.264: 1280 x 720 / 640 x 368 / 640 x 360 / 160 x 90
M-JPEG: 1280 x 720 / 640 x 368 / 640 x 360 / 160 x 90
MPEG-4: 1280 x 720 / 640 x 368 / 640 x 360 / 160 x 90
Frame Rate Up to 15fps for all resolutions
Image Setting AE, AWB
3D Noise Reduction
Color, Brightness, Sharpness, Contrast, Hue
Mirror / Flip
10 Privacy Masks
Text, Time and Date Overlay
Streaming Simultaneous multi-profile streaming
Streaming over UDP, TCP, or HTTP
M-JPEG streaming over HTTP (server push)
Supports 3GPP mobile surveillance (MPEG4)
Controllable frame rate and bandwidth
Constant and variable bit rate (MPEG4 / H.264)
ROI
Audio
Audio Streaming 2-way Audio
Audio Compression RTSP: G.711 64kbps, G.726 32kbps
3GPP: AMR
Microphone Internal microphone and speaker input
Audio Output Adjustable audio output gain
Network and Configuration
Network Standard IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX
IEEE 802.11 b/g/n
Network Protocol IPv4, IPv6, TCP/IP, UDP, HTTP, HTTPS, SMTP, FTP, NTP, DNS, DDNS, DHCP, ARP, Bonjour, UPnP, RTSP, RTP, RTCP, IGMP, PPPoE, 3GPP, ICMP, Samba
Antenna Connector 1×2 dBi (max) dual detachable diversity antenna
Frequency 2.4GHz
RF Transmit Power OFDM: 14 dBm
CCK: 17 dBm
RF Receiver Sensitivity 802.11b (11Mbps): CCK@8% PER = -88dBm
802.11g (54Mbps): OFDM@ 10% PER = -72dBm
802.11n Draft 6.0: HT20@ 10% PER = -66 dBm
HT40@ 10% PER= -61dBm
RF Data Rate 802.11b: 1, 2, 5.5, 11Mbps
802.11g: 6, 9, 12, 24, 36, 48, 54Mbps
802.11n (20MHz) : up to 72Mbps
802.11n (40MHz) : up to 150Mbps
Security Password protection, IP address filtering, HTTPS encrypted data transmission, user access log, WEP and WPA encryption
Users 20 clients on-line monitoring at the same time
System Integration
Application Programming Interface Open API for software integration
ONVIF
Alarm Triggers Intelligent Video Motion Detection
External Input
PIR detector (Human Detect)
Audio detection
Alarm Events File upload via FTP, Samba, SD card or email
Notification via email, HTTP, and TCP
External output activation
Audio alert output
Video Buffer Pre and post alarm buffering
Environment
Power Requirements 12V DC, 1A
Power Consumption 7W (12VDC)
Operating Temperature -10 ~ 40 degrees C
Operating Humidity 20 ~ 80% (non-condensing)
Dimensions (W x D x H) 58 x 39 x 91 mm
Weight 146g
Emission CE, FCC
Connectors 10/100 Mbps Ethernet, RJ-45
DC power jack
Terminal block for 1 alarm input and 1 output
Audio out
TV out
Micro SD/SDHC card (max 32GB, class 6)
Factory default reset
