Server Rack Cabinet TOTEN 9U / Cabinet / Enclosure Rack / Enclosure – 9U, 19″. Size : (W600 x D450 x H501mm)
Server Rack Cabinet TOTEN 9U / Cabinet / Enclosure – 9U, 19″ (W600 x D450 x H501mm)
Model : W2.6409.9001.
Standard Features of Wall Mount Equipment Rack:
600 x 450 x 501mm (Width x Dept. x Height )
2 x 4-inch Fan (Low Noise) on Vented Top Flush Panel
2 x Side Door with Cam Lock
Front Door –Glass with Cam Lock
4 x Panel Mount with Unit Indication
1 x Integrated Wall Mounting Panel
1 x Power Distribution Unit (6 Way PDU)
1 Packet of M6 Cage Nuts Assembly
Finish with Epoxy Powder Coating
Type :Wall Mount Equipment Rack
Color : Black
Comply with ANSI/EIA RS-310-D、IEC297-2、DIN41494;PART1、DIN41494;PART7, ETSI standard.
Features of Server Rack Cabinet TOTEN 9U:
Welded frame, reliable structure;
Standing or wall mounting installation;
Adjustable feet and heavy duty castors are optional;
Easy mounting installation (patent);
19” standard installation;
Removable side panels, side locks optional;
Cable entry on both of top cover and bottom panel;
120mm fan available;
Turning angle of front door is over 180 degrees.
SPCC cold rolled steel;
Thickness: mounting profile 2.0mm, mounting angle 1.5mm, others 1.2mm.
Degreasing, pickling, phosphoric, powder coated;
Degree of protection:
Static loading: 60KG
TOTEN runs under ISO9001:2000 certification. They have passed the strict test, and gotten the certification of SGS for years.
To ensure the quality and the manufacturing capacity our products, TOTEN has invested heavily to import advanced manufacturing equipment abroad: 5 Germany TRUMPF high-speed hydraulic turret punch presses, 1 Japan AMADA hydraulic turret punch presses, 2 Germany TRUMPF laser cutter, 33 press brakes, 4 spraying painting lines and 50 common punch presses.
