4050 Mould CNC Router- Mini Shoes mould engraving machine

4050 Mould CNC Router- Mini Shoes mould engraving machine

Applicable Scope：
Small and medium auto parts mould, plastic mold, stamping mold, high
frequency mold, coperelectrode, special precision instruments, graphite,
ink stone, shoe mold, hot stamping mold, jade carving, jewelry, stamps,
jewelry, wood products, advertising signs , nameplates, signs, breastplate,
crystal words, Blister light boxes, hot stamping board, PCB Board,
instrument panel, mobile phone panel, circuit board, electrical equipment
panels, moon cake mold,iron, copper, aluminum, plastic sheeting etc.

Performance Features：
1. Better rigidity, casting structure for host base, beams and columns.
2. Adopt Fully enclosed or semi-closed soundproof design.
3. Imported high-precision ball screw and Taiwan linear guide.
4. Equipped with high-speed spindle, ensuring high precision.
5. Moving table design ensure the processing accuracy effectively.
6. All guide rails are installed under scraping and grinding method.
8. Imported servo system, high precision engraving, can work long 'hours, with fault alarm and automatic shutdown function;
8. Analyze the whole machine with finite element analysis method,' maximize the potential of each components.

Technical Parameters:
Model
BD-4050
Driving System
Servo motor
Working Stroke
400*500 mm
Feeding Height
250 mm
Max Motion Speed
10 m/min
Max Processing Speed
5 m/min
Spindle Power
3KW frequency water cooling
Spindle Speed
6000-24000 rpm/min
Working Voltage
AC380V50HZ
Engraving Tools
¢3.175/4/6/12.7mm
Command Format
G Code/ HGPL
Position Accuracy
± 0.02mm
Repeatability
±0.01mm
Controlling System
NC Studio
