Energex DSP Pure Sine UPS/IPS 3 KVA LCD-Disp 5Yrs Warranty

¬ World’s Most Advanced DSP Technology. ENERGEX DSP (Digital Signal Processor) UPS/IPS PURE SINE WAVE LCD-Display. Capacity: 1 KVA – 10 KVA.
600VA, 850VA, 1000VA, 1200VA, 1600VA, 2000VA, 2500VA, 3000VA, 4000VA.
5000VA, 6000VA, 7000VA, 8000VA, 10000VA.
*ENERGEX DSP PURE SINE WAVE COMMERCIAL LONG BACK-UP UPS/IPS (600 VA-10000 VA) based on World’s most advanced Digital Signal Processor (DSP) Technology. IT is safest combination of UPS/IPS/ Inverter, The power it supplies is actually purer than the power supplied from the mains. This is clearly evident, as appliances don’t make any irritating, humming sound as they do on normal UPS in the market.

Your sensitive and expensive equipment will be correctly powered by ENERGEX DSP COMMERCIAL UPS, Which an ordinary UPS cannot supply the right kinds of power to run the equipment. ENERGEX UPS gives the right charging for the batteries ensuring life and less toping up for your batteries.

*All the application such as Power tools, Lights, Fans, LCD-TV, Satellite Receiver, Computer, Printer, Monitor, Scanner, Washing machine, Water pump, Microwave Oven, Server, Refrigerator, Air Conditioner, EPABX, Intercoms, Photo-Copier, Type Writer , Medical Instrument etc, over the years, any residential and commercial unit, can run all together, which requires uninterrupted power back-up source, 220 V @ 50Hz Pure Sine Wave Output. An ordinary UPS is not equipped with the power to support and run multiple appliances that draw enormous energy from source.

* DSP BASED PWM TECHNOLOGY USING MOSFET: DSP is the most powerful technologies and is meant for high speed processing application. This helps in saving loss of power, which happens during the process of power by the normal UPS.

* PURE SINE WAVE OUTPUT: Pure Sine Wave 100% clean, Regulated, and completely stable and distortion free power, which is absolutely safe to running sophisticated appliance without humming& irritating, sound.

* LCD- will display! Battery Voltage, Inverter output Voltage, Inverter Load in Watt. Charger on/off& Charging Ampere., UPS Mode/Inverter Mode, Inverter/UPS Standby on/off, Mains AC Voltage etc.

* PROTECTION YOUR APPLIENCE : A feature, which is automatically switch on to battery mode in case there is extreme high or low voltage supplied from the mains, hence protecting valuable equipment

* Protection against: Over load, short circuit, battery dip discharge, battery over charge, main over voltage, reverse connection or phase and neutral of mains input. In all these error condition will be shown in the LCD display.

* INSTANT SWITCHOVER: In case of power failure, the process of switchover to the battery mode is a few milliseconds, hence the power supplied to the connected appliance s, like computers is not interrupted, as a result of which the system does not reboot.

* CONSTANT SUPPLY OF POWER: The voltage supplied by the UPS during power failure will not differ with the increase or decrease in the load. The voltage & frequency
At the battery mode will be constant and will not affected by increase or decrease in the load.

* LONGER BATTERY LIFE: DUE TO SMPS FUZZY LOGIC CHARGING TECHNIQUE ENERGEX DSP UPS protect the battery, reduce frequently of water topping and
Enhances battery life by sensing the requirement of charging required by the battery.
(Charger working range: 130 – 270V). Charging Current: 5 A – 30 A settable. Fast and powerful charger with 10A and 30A.

* HIGH TEMPERATURE WARNING & OVER TEMPERATURE SHUTDOWN: In
Case of excessive heating, the system will display warning and shutdown automatically.

* 20 KHz operating frequency while inverter and charging, absolutely no sound.

* Capable of driving reactive & capacitive load at start moment.

* Cycle-Cycle current limiting. This is enhanced Protection method for the short circuit/
Heavy load condition.

* Thermal controlled double Turbo cooling fan.(Both CKR & Transformer ) For Extra Long Back-Up.

* Delayed inverter cutoff for condition like battery low, overload, short circuit etc. the system will be automatically restart from cutoff after a few second buzzer beeps the system will go to permanent cutoff if the error condition exists even after 4 restart.

* GREAT MONEY SAVER: ENERGEX DSP Commercial UPS can be installed with: 1 KVA=1Battery, 2 KVA=2 Battery, 3 KVA=3 Battery, 4 KVA= 4 battery, 5 KVA= 5 battery, built in technology it helps carry the load with lesser number of batteries and saves a considerable amount of space and money.

* REDUCE ELECTRICITY BILLS: ENERGEX DSP COMMERCIAL UPS has been designed with a very low load power consumption, which saves many units per year helping to reduce electricity bill. Its superior back up mode makes it 90% more efficient than any other UPS today.

* HIGH initial current: ENERGEX DSP COMMERCIAL UPS can effortlessly run heavy
-duty appliance which require high initial current for start-up such as photocopier,
Water pump, refrigerator, laser printer etc.

ENERGEX POWER SYSTEM
5Yrs Warranty For Control unit. ( BATTERY LIFE APPROXIMATELY 3-5 YEARS.)

3. Remark: Customized specifications are accepted.

Product Specification
For Home and office
Output Power: 400VA – 10KVA
Warranty: 5 Year’s
Waveform: DSP ( Digital Signal Processor) Pure Sine Wave
Technology: IGBT/ Mosphet based PWM technology
Voltage: 12 V-96V
AC voltage: 220V/50Hz

Fully Automatic
DSP ( Digital Signal Processor) Based.
Low battery protection
Battery over charge protection
Battery deep discharge protection.
Overload & short circuit protection
LCD display. ( 1- 4 Line)
Long Battery backup time.
Long Battery Life.
Battery Automotive / Battery Tubular Selectable.
Mosfet & IGBT based circuit board
Transformer with genuine South Korean silicon core.

Supported 12V DC Batteries
Hamko, Lucas, Volvo, Voltex, Navana, Spark, General, Lumens, Apollo, Leader, Diamac and Maintenance free battery,
---------------------------------------------------
## IPS only machine/unit Price list ##
---------------------------------------------------

400VA IPS only machine price- 6,000 BDT
625VA IPS only machine price- 8,000 BDT
800VA IPS only machine price- 9,500 BDT
1000VA IPS only machine price- 11,500 BDT
1250VA IPS only machine price- 16,500 BDT
1500VA IPS only machine price- 20,000 BDT
2000VA IPS only machine price- 25,000 BDT
2500VA IPS only machine price- 30,000 BDT
