| AINOL SPARK AX7 8-CORE DATA |
| ONLY ONE COLOR(FRONT WHITE AND BACK GOLDEN) |
| DETAILS | MODEL | Novo 706KC-M1 |
| structure | Metal and plastic |
| OS | Android 4.4.2 |
| OPERATING | 10 POINTTouch capacitance screen+buttons（power、VOL-、VOL+） TP OGS PROCESS 40 CHANNELS |
| GPU | mail450mp4 |
| CPU | MT6592 8-CORE |
| SCREEN | 7.0" IPS SCREEN |
| SCREEN DEFINITION | 1920*1200 FULL HD SCREEN |
| RAM | 16G |
| DDR | 1G |
| CAMERA | FRONT 2.0MP REAR 5.0MP（CHIPS: FRONT GC2235、REAR: OV5647）WITH FLASH LIGHT（WITH light, distance sensor） |
| G-sensor | 3 shaft G-sensor high sensitivity accelerometer |
| BATTERY | 12WH 3300mAH |
| plug-in | SUPPORT FLASH |
| Vibration motor | YES |
| OUT PLAYER | 8OHM 1W HORN |
| call | SUPPORT DUAL CARD DUAL STANDBY, ONE STANDARD PORT AND ONE MICRO PORT |
| | GSM850/900/1800/1900 FULL FREQUENCY |
| 3G FREQUENCY | WCDMA2100 |
| GPS | YES |
| FM | ONLY SUPPORT RECEIVING |
| FM FREQUENCY RANGE | 76MHZ-108MHZ |
| NETWORK | BUILT-IN wifi | USING MT6627 FOUR-IN-ONE CHIP，SUPPORT 802.11b/g/n，MAX. 150M，feature: can set stay online during dormant state |
| BLUETOOTH VERSION | V4.0 |
| PLAYING TIME | MUSIC | around 38h using headphone, without wifi and shutdown screen |
| 3D GAME | around 4h without wifi |
| web | 50% brightness about five hours and 30 minutes |
| ONLINE VEDIO | outside Sound, darkest brightness, 50% sound, around six hours and 45 minutes |
| VEDIO | outside Sound, darkest brightness, 50% sound, around six hours and 25 minutes |
| VIDEO PLAYING | FORMAT | AVI、3GP、MP4、MKV、WEBM、FLV、MOV |
| Video coding | H.264、AVC1、XVID、DX50、Mp4v、S263、MP4V、MPEG2 VIDEO、VP80、MPEGlpayload |
| Model resolution | AVI：1920X1080、3GP：352X288、MP4：1280X720、MKV：1920X1080、WEBM：1280X720、MOV：1920X1080、MPG：720X480、VOB：1024X576 |
| Hardware and software | YES |
| Multi tracks switch | YES |
| Search local video | YES |
| Breakpoint play | YES |
| Brightness control | YES |
| track | YES |
| Video proportion | YES（Full screen according to the video proportion、original size、4：3、16：9） |
| Subtitle size | YES |
| Subtitle color | NO |
| Subtitles selection | YES |
| subtitles | support SRT、SSA、ASS、SMI and MKV embedded display subtitles |
| Audio performance | Signal to noise ratio | MORE THAN 90db |
| The degree of distortion | LESS THAN 0.6% |
| Headphone output power | （L）10mw （R）10mw（32ohm） |
| Music format | WAV、MP3、MP2、AAC、AMR、AWB、MIDI、OGG、FLAC |
| Circulation patterns | Repeat all, repeat current |
| Random broadcast | YES |
| Album cover | YES |
| Function note | Above for the function of built-in player, can install different players, function according to the installed music player software |
| Image | Image format | JPG、PNG、BMP、GIF |
| Larger/smaller/rotate | YES |
| Rotate to the left/right | YES |
| The thumbnail display | YES |
| slide | YES |
| Set as desktop background | YES |
| E-BOOK | Ebook format | WORD、EXCEL、POWERPOINT、PDF、TXT(NEED TO INSTALL 3RD SOFTWARE) |
| RECORDING | MIC recording format | 3GPP |
| The recording mode | THROUGHT MIC |
| The recording time | cumulatively 55 hours the longest（8GB capacity） |
| SETTINGS | language | Chinse、English and others |
| The clock function | YES |
| The calendar function | YES |
| Function of remote control | NO |
| The game features | YES（NEED TO INSTALL 3RD SOFTWARE） |
| Support operating system | Windows XP win7 win8 win8.1 |
| PORT AND OTHERS | Transport interface | USB2.0 port |
| standard headset | 3.5mm headphone output |
| The use of temperature | BELOW 10 ℃ TO 45℃ |
| OTG | YES（SUPPORT exfat，NTFS，fat32 FORMAT） |
| external usb drive | YES |
| External sd card | MAX. SUPPORT 32GB |
| Charging way | USB charging (shutdown phonoe and screen saver mode) and maximum charging current 1.2 A |
| TV OUTPUT | color difference | NO |
| HDMI | NO |
| SIZE | | 189*107.5*8.1 |
