NEC 17" DESKTOP MONITOR

SPECIFICATIONS
Picture Tube/Display 17-inch (16.0" viewable image size) flat square technology CRT, 0.28 mm trio dot pitch, 90 degree deflection, 1210 mm radius, medium-short persistence phosphor, anti-static screen coating, semi-tint screen, Invar shadow mask, OptiClear screen surface
Input Video Signal ANALOG 0.7 Vp-p / 75 Ohms Positive
Sync Separate TTL level
Horizontal Positive/Negative
Vertical Positive/Negative
Composite TTL level, Positive/Negative

Display Colours Analog Input: Unlimited Colours (Dependent upon display card used)
Synchronisation Range (Automatic) Horizontal 31 kHz to 69 kHz
Vertical 55 Hz to 120 Hz

Resolutions Supported
640 x 480 @ 60 to 120 Hz

800 x 600 @ 55 to 109 Hz

832 x 624 @ 55 to 103 Hz

1024 x 768 @ 55 to 85 Hz (Recommended)

1152 x 870 @ 55 to 76 Hz

1280 x 1024 @ 55 to 65 Hz
NOTE: Some systems may not support all modes listed.

Active Display Area (Factory Setting) Horizontal 270 mm / 10.6 inches
Vertical 202 mm / 8.0 inches
(Dependent upon signal timing used)

Active Display Area
(Full Scan) Horizontal 280 mm / 11.0 inches
Vertical 210 mm / 8.3 inches
(Dependent upon signal timing used)

Power Supply AC 220 - 240V AC, 50/60 Hz
Signal Cable Captive 15-pin mini D-SUB connector
Dimensions:Net Net: 403 mm (W) x 427 mm (H) x 440 mm (D)
Weight Net:17.5 kg
Operating Temperature +5 degrees C to +35 degrees C
Operating Humidity Range 30% to 80%
Operating Altitude 0 to 10,000 Feet
Storage Temperature -20 degrees C to +60 degrees C
Storage Humidity Range 10% to 90%
Storage Altitude 0 to 45,000 Feet
Power Management
IPM (Intelligent Power Manager) system

EPA Energy Star

NUTEK based on VESA DPMS 4 states

User Controls
Power

Degauss

Brightness

Contrast

reset

horizontal size

horizontal position

vertical size

vertical position

basic geometry(sides in/out; left right balance; tilt; align; rotate)

AccuColour

OSD background colours

exit
